| Max Full Rotary Speed | 120m/min |
| Max Semi Rotary Speed | 60m/min |
| Accuracy of Cutting | ±0.15mm(Adhesive) |
| Accuracy of IML Cutting | ±0.20mm(IML) |
| Inspection Speed | 80m/min (Option Inspection camera) |
| Max Web Width | 550mm |
| Max Cut Repeat | 444.5MM(Standard magnetic cylinder140Teeth) |
| Max Die Cutting Width | 530mm |
| Max Cut Area | 530*444.5mm |
| Max Unwinding Dia. | φ800mm |
| Max Rewinding Dia. | φ800mm |
| Auto Stacking Height | 100mm(Option Automatic stacking system) |
| Thickness of Material | 60μm-300μm |
| Power | 16KW |
| Voltage | 380V/50HZ |
| Weight | 3500KG |
| Overall: | 2800*1630*1600mm |
